NBP405nm narrow bandpass filter
405nm narrow-band filter is used for enzyme labeling instrument.
405nm narrow-band filter adopts ion sputtered multilayer dielectric film, which has high environmental resistance and stability. Since no absorption filter is used, there are few temperature rise caused by absorption hot wire or element degradation caused by absorption of ultraviolet light, which can be used for various light sources
Main application fields of 405nm narrow-band filter: fluorescence analyzer, enzyme marker, cable TV upgrade equipment, wireless transmission equipment, mobile phone bar code scanning, infrared electronic whiteboard, infrared camera, infrared touch screen, iris recognition, infrared medical instrument, infrared ink recognition, red film recognition, face recognition sensor system. Hand held infrared laser rangefinder, laser rangefinder, optical instruments, medical and health equipment and testing instruments.
| Item | Parameters |
| Product name | NBP405nm narrow bandpass filter |
| Model number | NBP405nm |
| Description | High Reflection Filters |
| Process | IAD Hard Coating |
| Centralwavelength(CWL) | 405±5nm |
| FWHM | 10±3nm |
| Transmittance | T＞60%@340±5nm |
| Cut off rate: | OD4 200-1100nm |
| Raw material | BK7 or Corning gorilla glass or other optical glass |
| Surface quality(S/D) | 60/40 or better |
| Dimension | Customized |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
Tags: optical filter , narrow band optical filter , Long Pass Filter , Short Pass Filter , Band Pass Filter , UV IR Cut Off , 532nm notch filter , custom bandpass filter , 940nm bandpass filter , ir bandpass filter , uv band pass filter , infrared bandpass filters
