LP520nm Long pass filter
As an important optical element, long wave pass and short wave pass filters are widely used in digital imaging, biomedical beauty, fingerprint recognition and other fields. Their characteristic is to let the light in one band pass through and cut off the light in another band. The long wave pass and short wave pass filters produced by UTE Optics have the characteristics of high transmittance, wide cut-off band and good film firmness.
| Item | Parameters |
| Product name | LP520nm Long pass filter |
| Model number | LP520nm |
| CWL | 520±3nm |
| Transmittance | T＞90% |
| Transmitting wavelength | 530-1100nm |
| Cutoff wavelength | 350-510nm |
| Blocking depth | >OD3-OD6 UV-NIR |
| Raw material | BK7,D263T,JGS1,Corning gorilla glass or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension/Round Size | D12x6mm D15x5mm |
| Dimension/Square size | 80x80x1mm |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
