LP530nm Long pass filter
530nm long wave pass filter is used for beauty instruments, strong light flashlight, stage light color film, face recognition attendance meter, optical instruments, optical fiber lighting, gold halogen lamp heat insulation, cold light source display cabinet and police multi band detection instrument
| Item | Parameters |
| Product name | LP530nm Long pass filter |
| Model number | LP530nm |
| CWL | 530±5nm |
| Transmittance | T＞90% |
| Transmitting wavelength | 540-1100nm |
| Cutoff wavelength | 350-520nm |
| Blocking depth | >OD3-OD6 UV-NIR |
| Raw material | BK7,D263T,JGS1,Corning gorilla glass or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension/Round Size | D12x6mm D15x5mm |
| Dimension/Square size | 80x80x1mm |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
