LP590nm Long pass filter
Application fields of 590nm long wave pass filter: white LED, gold halogen lamp, optical fiber lamp, visible light source, beauty instrument, police multi band detection instrument, strong light flashlight, stage light color chip, face recognition attendance instrument, optical instrument, optical fiber lighting, gold halogen lamp heat insulator, light source display cabinet.
| Item | Parameters |
| Product name | LP590nm Long pass filter |
| Model number | LP590nm |
| CWL | 590±5nm |
| Transmittance | T＞90% |
| Transmitting wavelength | 600-1100nm |
| Cutoff wavelength | 200-580nm |
| Blocking depth | >OD3-OD6 UV-NIR |
| Raw material | BK7,D263T,JGS1,Corning gorilla glass or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension/Round Size | D12x6mm D15x5mm |
| Dimension/Square size | 80x80x1mm |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
Tags: optical filter , narrow band optical filter , Long Pass Filter , Short Pass Filter , Band Pass Filter , UV IR Cut Off , 532nm notch filter , custom bandpass filter , 940nm bandpass filter , ir bandpass filter , uv band pass filter , infrared bandpass filters
