LP770nm Long pass filter
770nm long wave pass filter is used for LED lighting, medical testing instruments, beauty photon machine equipment, multi band detector, optical fiber lighting, stage lighting system, iris recognition and digital image applications.
| Item | Parameters |
| Product name | LP770nm Long pass filter |
| Model number | LP770nm |
| CWL | 770±5nm |
| Transmittance | T＞90% |
| Transmitting wavelength | 780-1100nm |
| Cutoff wavelength | 200-760nm |
| Blocking depth | >OD3-OD6 UV-NIR |
| Raw material | BK7,D263T,JGS1,Corning gorilla glass or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension/Round Size | D12x6mm D15x5mm |
| Dimension/Square size | 80x80x1mm |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
Tags: optical filter , narrow band optical filter , Long Pass Filter , Short Pass Filter , Band Pass Filter , UV IR Cut Off , 532nm notch filter , custom bandpass filter , 940nm bandpass filter , ir bandpass filter , uv band pass filter , infrared bandpass filters
