SP670nm short pass filter
Short wavelength pass filters, as an important optical component, are widely used in digital imaging and biomedical cosmetology, fingerprint identification and other fields, and are characterized by allowing light in a certain wavelength range to pass through, while allowing light in another wavelength range to be cut off.
UTE Optics specializes in the production of short wave pass filters, which can effectively cut off the light in the near-infrared band. They are widely used in various cold light sources, optical fiber lighting, LED lighting, gold halogen lamp heat insulation, and optical imaging schemes applied on infrared cut-off filters: optical engine, digital camera α Cdcmos near infrared interference filter to ensure the normal operation of photoelectric instruments and equipment.
| Item | Parameters |
| Product name | SP670nm short pass filter |
| Model number | SP670nm |
| Central wavelength(CWL) | 670±5nm |
| Transmittance | T＞90% |
| Transmitting wavelength | 350-670nm |
| Cutoff wavelength | 680-1100nm |
| Blocking depth | >OD3-OD6 UV-NIR |
| Raw material | BK7,D263T,JGS1,Corning gorilla glass or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension | Customized |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
